DIMENSIONS
Length 293.62 mm
Overall Width 830.58 mm
Overall Height 1160.78 mm
Seat Height:
- Laden 673.10 mm
- Unladen 711.20 mm
Ground Clearance 111.76 mm
Rake (steering head) 30.1°
Fork Angle 30.1°
Trail 119.38 mm
Wheelbase 1534.16 mm
Tires (Dunlop® Harley-Davidson® Series, blackwall):
- Front – D402F MH90-21 54H
- Rear – D401 150/80B16 71H
Fuel Capacity 17.03 L
Oil Capacity (w/filter) 3.41 L
Transmission Capacity 0.95 L
Weight:
- As Shipped 256.28 kg
- In Running Order 268.07 kg
- Gross Vehicle Weight Rating 453.59 kg
Gross Axle Weight Rating:
- Front 151.95 kg
- Rear 301.64 kg
ENGINE
Engine Air-cooled, Evolution®
Valves Pushrod-operated, overhead valves with hydraulic,self-adjusting lifters; two valves per cylinder
Bore x Stroke 76.20 mm x 96.77 mm
Displacement3 883 cu. cm
Compression Ratio 8.9:1
Fuel System4 Electronic Sequential Port Fuel Injection (ESPFI)
Air Cleaner Paper cartridge type
Lubrication System Dry-sump
DRIVETRAIN
Primary Drive Chain, 57/34 ratio
Final Drive Belt, 68/28 ratio
Clutch 9-plate, wet
Transmission 5-speed
Gear Ratios (overall):
1st 10.782
2nd 7.702
3rd 5.728
4th 4.748
5th 4.071
CHASIS
Frame Mild steel, tubular frame; circular sections; cast junctions
Swing Arm Mild steel, rectangular tube sections, stamped junctions; MIG welded
Front Forks 39 mm
Rear Shocks Coil-over; preload dual-adjustable
Wheels
- Front Chrome, Laced Steel 533.40 mm x 54.61 mm
- Rear Silver, Solid Disc Cast Aluminum 406.40 mm x 76.20 mm
Brakes:
- Caliper Type Dual-piston front, single-piston rear
- Rotor Type (diameter x width): Patented, uniform expansion rotors
- Front 292.10 mm x 5.08 mm
- Rear 292.10 mm x 5.84 mm
Suspension Travel:
- Front Wheel 144.53 mm
- Rear Wheel 53.85 mm
ELECTRIC
Battery Sealed, maintenance-free, 12V, 12-amp/hour, 200 cca
Charging Single-phase, 30-amp system (357W @ 13.5V, 2000 rpm, 405W max power @ 13.5V)
Starting 1.2 kW electric with solenoid shift starter motor engagement
Lights (as per country regulation):
- Headlamp (quartz halogen) 55-watt low beam, 60-watt high beam
- Tail/Stop Lights 8W/28W (5W/21W)
- Turn Signal Lights 28W (21W) self-canceling
- Indicator Lamps High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warnings, security system8 (optional)
STYLING/CONVENIENCE
Exhaust System Chrome, staggered shorty exhaust with dual mufflers
Fenders and Supports
- Front Sport fender with painted brace supports
- Rear Full coverage fender with chrome supports
Foot Supports and Controls
- Rider Forward-mounted footpegs with brake & shift levers
- Passenger Standard footpegs
Handlebar Style Stainless steel, low-rise
Seat Type and Style One-piece, two-up Sportster® classic
Fork Lock Common with ignition key
Hazard Warning Integrated into turn signal controls
Smart Security System Next-generation hands-free security fob;
operates based on proximity to vehicle
COLORS
Vivid Black
